Vibratingscreen

1000-3F Scraper Rotary Vibrating Screen Shipping for Chile

xgtu — Mon, 17 Apr 2023 09:24:19 +0000

Scraper rotary vibrating screen is one kind of customized vibrating screen by adding one extra rotating scrap brush or silicon plate on the original basis vibrating screen, which is mainly for scattering the powder or granules which easy aggregate so as to increase the screen mesh passing rate and getting the higher capacity.

600-8M Truck Loading Belt Conveyor shipping to Laos

xgtu — Mon, 17 Apr 2023 08:53:43 +0000

This series inclined black rubber belt conveyor is widely used for truck loading unloading in ware house, grain depot, seaport or airport. There are different width from 500mm to 1500mm for variety application, different length from 5Meters to 15Meters as per different loading height. One of our Laos customer ordered model 600MM width 8 Meters which can get 2.5-3.5 meters high. The belt conveyor is too long to delivery, so we disassembled at two parts, and all supporting roller, wheels is packed in plywooden box. The customer can assemble together by the video instructions.

Difference of Shaft Screw Conveyor with Shaftless Screw Conveyor

xgtu — Fri, 14 Apr 2023 10:46:58 +0000

The screw conveyor also called auger conveyor,it is a kind of machine that uses the motor to drive the screw to rotate and push the material to achieve the purpose of conveying. It can be transported horizontally, inclined or vertically, and has the advantages of simple structure, small cross-sectional area, good sealing, convenient operation, easy maintenance, and convenient closed transportation. Screw conveyor is a continuous conveying equipment widely used in metallurgy, building materials, chemical industry, grain and mechanical processing and other departments.

There are two types as per structure design: shaft screw conveyors and shaftless screw conveyors in terms of conveying form, and U-shaped screw conveyors and tubular screw conveyors in terms of shape.

So what is the difference between a shaft screw conveyor and a shaftless screw conveyor?

The shafted screw conveyor is suitable for non-viscous dry powder materials and small particle materials such as: cement, fly ash, lime, grain, etc. , while the shaftless screw conveyor is suitable for conveying viscous and easily entangled materials such as sludge, biomass, garbage, etc.
The shafted screw conveyor has low power consumption and higher productivity. Shaftless screw conveyor is a kind of environmental protection equipment that has no central axis and relies on the rotation of the spiral screw blade to transport materials. It is mainly used to transport sludge and grid slag from various sewage treatment plants. There are also the wearing nylon protective liner inside the trough.
The conveying angle of the shaftless screw conveyor generally cannot exceed 30 degrees, because it is easy to cause the material to fall off when conveying the material, while the shafted screw conveyor is supported by the screw shaft, the conveying angle can exceed 30 degrees, and it can even be achieved close to conveying at vertical direction.
The capacity of the shaftless screw conveyor is 1.5 times than that of the shaft screw conveyor. Because there is no intermediate shaft, has more volume in the conveying pipeline, and the material is not easy to be blocked and can be quickly conveyed along the direction of the spiral rotation.

Different structure machine is for different application, if you are hesitate to decide which type to choose, pls contact us about your specific request, we can analysis and choose the right model for you.

1200MM-3F Rotary Vibrating Screen for Spain

xgtu — Fri, 14 Apr 2023 08:06:12 +0000

1200MM is the medium size rotary vibrating screen, 3 Layers is with 4 outlets, which is for 4 different size grading and sieving, it is made for plastic granules sieving in the plastic recycling industry.

The machine is 3P-380V-50HZ electricity, the construction is at contact parts stainless steel S304, the base part is carbon steel. It is equipped with screen mesh 12#, 14#, 20#.

600mm-4F Rotary vibrating screen sending for Philipine

xgtu — Fri, 18 Nov 2022 06:56:31 +0000

Rotary vibrating screen is one kind of universal compact sieving machine which widely used in food related powder and granules sifting, chemical powder sieving, mineral industry screening, grains sorting etc.

600mm is the smaller size in rotary vibrating screen category, which can handle within 100kgs as per different mesh size and different material density, 4 Layers with 5 outlets can grade the powder in 5 different mesh size. It was sent to Philipine. Customer use it for coconut sugar granules sieving in mesh size 20#, 25#, 30#, 35#, 40#, the machine is constructed at contact parts stainless steel s304 which is food grade and rust free, the bottom base at carbon steel at gray color.

4 Layers rotary vibrating screen

600mm rotary vibrating sieve

400mm dia 1 Layer Vibrating Screen

xgtu — Fri, 18 Nov 2022 04:03:11 +0000

This is the smallest size 400mm diameter in the category of rotary vibrating screen, It is 1 layer at mesh 80# with two outlets. It was ordered by Zambia customer who bought it for baobab powder sieving. As per request, it is single phase 220V 50HZ with English standard plug, and the machine contact parts at stainless steel S304 which is food grade for food powder, chemical powder, pharmacy powder etc.

600MM-2F Direct Discharge Vibrating Screen

xgtu — Fri, 18 Nov 2022 03:57:34 +0000

Direct discharge vibrating screen is mainly for coarse sieving, it is generally equipped with single layer. As per customer’s special request, we add one more layer to make it at double layers which equipped with mesh 4# and 60#, at the same time they also ordered 600-2F Rotary vibrating screen which equipped with 30mesh with 50mesh, The customer buying it for plastic granules sieving and grading.
